Life Latch® New Generation

Description

User friendly Screw-top Pail provides the ultimate protection for your products.



Open & Closing Instructions:

Select size for product specs

0.6 Gallon Life Latch® NG Pail1.25 Gallon Life Latch® NG Pail2.0 Gallon Life Latch® NG Pail2.5 Gallon Life Latch® NG Pail3.5 Gallon Life Latch® NG Pail5.0 Gallon Life Latch® NG Pail5.0 Gallon Life Latch® NG Pail – Slotted Lid5.5 Gallon Life Latch® NG Pail6.5 Gallon Life Latch® NG Pail

Product Specs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Weight: 0.166 lbs. / 75 g
Height: 1 3/8”
Min Wall Thickness: 0.046”
Bottom Outside Diameter: 7”
Gasket: Neoprene / Available w/o Gasket
Fitments: Please inquire about custom fittings
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 180 per case / 1,440 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Handles: Plastic
Weight: 0.36 lbs. / 162 g
Exterior Height: 6 7/8” With Cover 7 3/8”
Min. Wall Thickness: 0.049”
Inside Diameter - Top: 6 1/8”
Outside Diameter - Bottom: 5 5/8”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 780 Units per Pallet | 28,080 Units per Truckload
Print Area: 3 3/4” x 18 1/4”
Top Load Rating: 125 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Weight: 0.321 lbs. / 148 g
Height: 1 3/4”
Min Wall Thickness: 0.050”
Bottom Outside Diameter: 8 7/8”
Gasket:  EPDM Tubular
Fitments: Please inquire about custom fittings
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 90 per case / 720 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Handles:  Metal or Plastic
Weight: 0.69 lbs. / 313 g
Exterior Height: 8 1/2” With Cover 9 1/8”
Min. Wall Thickness: 0.062”
Inside Diameter - Top: 7 3/4”
Outside Diameter - Bottom: 7”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 400 Units per Pallet | 14,400 Units per Truckload
Print Area: 5” x 22 3/4”
Top Load Rating: 175 lbs.

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding
Weight: .76 lbs / 345g
Height: 2.41”
Min Wall Thickness: .075”
Bottom Outside Diameter: 11.72”
Gasket: Neoprene / Available w/o Gasket
Standard Color:  White, Red 186, Blue 300 (Please inquire about custom colors)
Shipping Quantity: xx per case / 240 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding / Plastic Handle
Handles:  Metal or Plastic
Weight: .1.27 lbs / 579 g
Exterior Height: 8.13” With Cover 8.77”
Min. Wall Thickness: .090”
Inside Diameter - Top: 10.100”
Outside Diameter - Bottom: 9.36”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 8 Pails and Covers Per Case | 168 Units per Pallet | 5,208 Units per Truckload
Print Area: 4” x 29.75”
Top Load Rating: 300 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding
Weight: .76 lbs / 345g
Height: 2.41”
Min Wall Thickness: .075”
Bottom Outside Diameter: 11.72”
Gasket: Neoprene / Available w/o Gasket
Standard Color:  White, Red 186, Blue 300 (Please inquire about custom colors)
Shipping Quantity: 40 per case / 480 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding / Plastic Handle
Handles:  Metal or Plastic
Weight: 1.44 lbs / 654 g
Exterior Height: 9.80” With Cover 10.15”
Min. Wall Thickness: .075”
Inside Diameter - Top: 10.08”
Outside Diameter - Bottom: 9.40”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 8 Pails and Covers Per Case | 168 Units per Pallet | 5,208 Units per Truckload
Print Area: 5” x 29.75”
Top Load Rating: 300 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding
Weight: 1.03 lbs / 470g
Height: 2.50”
Min Wall Thickness: .090”
Bottom Outside Diameter: 12.69”
Gasket:  Neoprene / Available w/o Gasket
Standard Color:  White, Red 186, Blue 300 (Please inquire about custom colors)
Shipping Quantity: 20 per case / 240 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding / Plastic Handle
Handles:  Metal or Plastic
Weight: 1.84 lbs / 836 g
Exterior Height: 11.50” With Cover 12.19”
Min. Wall Thickness: .090”
Inside Diameter - Top: 11.25”
Outside Diameter - Bottom: 10.27”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 6 Pails and Covers Per Case | 144 Units per Pallet | 4,752 Units per Truckload
Print Area: 6.25” x 33”
Heat Transfer Area: 6.63” x 31.75
Top Load Rating: 375 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Weight: 1.04 lbs. / 471 g
Height: 2 1/2”
Min Wall Thickness: 0.090”
Bottom Outside Diameter: 12 3/4”
Gasket: Neoprene/ Available w/o Gasket
Fitments: Please inquire about custom fittings
Standard Color:  White (Please inquire about custom colors)
Shipping Quantity: 20 per case / 240 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Handles: Plastic
Weight: 2.36 lbs. / 1071 g
Exterior Height: 15 1/4” With Cover 16”
Min. Wall Thickness: 0.090”
Inside Diameter - Top: 11 1/4”
Outside Diameter - Bottom: 10 1/4”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 120 Units per Pallet | 4,320 Units per Truckload
Print Area: 9 1/2” x 33”
Heat Transfer Area: 8 1/2” x 31”
Top Load Rating: 425 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Weight: 1.03 lbs. / 470 g
Height: 2 1/2”
Min Wall Thickness: 0.090”
Bottom Outside Diameter: 12 3/4”
Gasket: Neoprene/ Available w/o Gasket
Fitments: Please inquire about custom fittings
Standard Color:  White (Please inquire about custom colors)
Shipping Quantity: 20 per case / 240 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Handles: Plastic
Weight: 2.36 lbs. / 1071 g
Exterior Height: 15 1/4” With Cover 16”
Min. Wall Thickness: 0.090”
Inside Diameter - Top: 11 1/4”
Outside Diameter - Bottom: 10 1/4”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 120 Units per Pallet | 4,320 Units per Truckload
Print Area: 9 1/2” x 33”
Heat Transfer Area: 8 1/2” x 31”
Top Load Rating: 425 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Weight: 1 lbs. / 471 g
Height: 2 1/2”
Min Wall Thickness: 0.090”
Bottom Outside Diameter: 12 3/4”
Gasket: Neoprene/ Available w/o Gasket
Fitments: Please inquire about custom fittings
Standard Color:  White (Please inquire about custom colors)
Shipping Quantity: 20 per case / 240 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Handles: Plastic
Weight: 2 1/4 lbs. / 1077 g
Exterior Height: 16 1/4” With Cover 17”
Min. Wall Thickness: 0.090”
Inside Diameter - Top: 11 1/4”
Outside Diameter - Bottom: 10 1/4”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 120 Units per Pallet | 4,320 Units per Truckload
Print Area: 9 1/2” x 33”
Heat Transfer Area: 8 1/2” x 31”
Top Load Rating: 425 lbs

Cover Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding
Weight: 1.03 lbs / 470g
Height: 2.50”
Min Wall Thickness: 0.090”
Bottom Outside Diameter: 12.69”
Gasket: Neoprene/ Available w/o Gasket
Fitments: Please inquire about custom fittings
Standard Color:  White, Red 186, Blue 300 (Please inquire about custom colors)
Shipping Quantity: 20 per case / 240 per pallet

Pail Specification

Origin of Materials: 100% US Manufactured
Material: High-Density Polyethylene (HDPE)
Mfg. Method: Injection Molding / Plastic Handle
Weight: 2.81 lbs / 1276 g
Exterior Height: 18.75” With Cover 19.45”
Min. Wall Thickness: .090”
Inside Diameter - Top: 11.25”
Outside Diameter - Bottom: 10.27”
Standard Color: White (Please inquire about custom colors)
Shipping Quantity: 2 Pails and Covers Per Case | 84 Units per Pallet | 3,360 Units per Truckload
Print Area: 10.5” x 33”
Heat Transfer Area: 11.4” x 31”
Top Load Rating: 400 lbs

Frequently Asked Questions

Common questions about the Life Latch® New Generation pail.

What Is a Tamper-Evident Lid?

A tamper-evident lid provides visible evidence when a plastic pail has been opened or altered after sealing, helping protect product integrity throughout storage, shipping, and handling.

Tamper-evident features can include tear bands, breakaway tabs, or other components that must be removed or broken when the container is opened for the first time. Once these features have been disturbed, it is easier to identify that the original seal has been opened.

Tamper-evident lids help protect product integrity and customer confidence throughout storage, transportation, and handling. They are commonly used for food products, chemicals, paints and coatings, industrial materials, and other applications where maintaining a secure closure is important.

M&M Industries offers a variety of plastic pails with tamper-evident closure options depending on the product line and application.

What Printing Methods Are Available for the Life Latch New Generation Pail?

The Life Latch New Generation pail is available with Heat Transfer Labeling (HTL) and Dry Offset printing.

Heat Transfer Labeling allows for detailed, high-quality graphics with vibrant colors, while Dry Offset printing is ideal for applying clean spot-color graphics directly to the pail. Both options allow customers to customize their Life Latch New Generation packaging with branded designs and product information.

What Fittings Are Compatible with the Life Latch New Generation Pail?

The Life Latch New Generation pail is compatible with Buna and Inverted Buna vents only. These venting options provide pressure or vacuum control for applications that require controlled airflow while maintaining a secure package.

Is the Life Latch New Generation Pail Designed for Liquids or Solids?

The Life Latch New Generation pail is designed for solids applications, not liquids. For applications requiring a liquid-rated option, M&M Industries offers the 5.0 Gallon Liquid Pail, designed specifically for liquid products.
